Deye 5kW Hybrid Inverter

CANBUS COMMUNICATION WITH LBSA BUILT UNITS

Straight PIN to PIN cable from CAN on the battery to CAN on inverter

Only use pins 4&5 on the RJ45 cable

Set battery type on the inverter to Lithium, Li 00

Higher Yields

User Friendly

Reliable

PV lightning protection
Anti-islanding protection
Leakage current protection
IP65 protection
Automatically switch from Grid-Tied to Off-Grid mode within 5ms
Zero export function – prevents the system from feeding in to the grid. NRS Approved
Fast reaction time is within 200ms in zero export mode

Smart

Model	SUN-5K-SG01LP1 -US
Battery Input Data
Battery Type	Lead-acid or Lithium-ion
Battery Voltage Range (V)	40~60V
Max. Charging Current (A)	120A
Max. Discharging Current (A)	120A
Charging Curve	3 Stages / Equalization
External Temperature Sensor	Optional
Charging Strategy for Li-Ion Battery	Self-adaption to BMS

PV String Input Data
Max. DC Input Power (W)	6500W
PV Input Voltage (V)	370V (100V~500V)
MPPT Range (V)	125V-425V
Start-up Voltage (V)	150V
PV Input Current (A)	11A+11A
No.of MPPT Trackers	2
No.of Strings Per MPPT Tracker	1+1

AC Output Data
Rated AC Output and UPS Power (W)	5000W
Max. AC Output Power (W)	5500W
Peak Power (off grid)	2 times of rated power, 10 S
AC Output Rated Current (A)	20.8A
Max. AC Current (A)	22.9A
Max. Continuous AC Passthrough (A)	35A
Output Frequency and Voltage	50 / 60Hz; 120 / 240Vac (split phase), 208Vac (2 / 3 phase), 230Vac (single phase)
Grid Type	Split phase; 2 / 3 phase; Single Phase
Current Harmonic Distortion	THD<3% (Linear load<1.5%)

Protection
PV Input Lightning Protection	Integrated
Anti-islanding Protection	Integrated
PV String Input Reverse Polarity Protection	Integrated
Insulation Resistor Detection	Integrated
Residual Current Monitoring Unit	Integrated
Output Over Current Protection	Integrated
Output Shorted Protection	Integrated
Output Over Voltage Protection	Integrated
Surge protection	DC Type II / AC Type II

Certifications and Standards
Grid Regulation	UL1741, IEEE1547, RULE21, VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IEC61727
Safety Regulation	IEC62109-1, IEC62109-2
EMC	EN61000-6-1, EN61000-6-3, FCC 15 class B

General Data
Operating Temperature Range (℃)	-25~60℃, >45℃ Derating
Cooling	Smart cooling
Noise (dB)	<30 dB
Communication with BMS	RS485; CAN
Weight (kg)	32
Size (mm)	420W×670H×233D
Protection Degree	IP65
Installation Style	Wall-mounted
Warranty	5 years
